EUROPA EOS 850 series is a new Economical Opening Frame System with simple straight lines design.

This system has two sizes of sashes (small – large), an adjoining profile and 23mm frame which are designed to accept Camera Europea Mechanism. Respectively there are two sashes (small – large) an adjoining profile and 29mm frame designed to cooperate with Multilocking Mechanism. In addition, there are two sizes of frames: small and large, the small frame is suggested to be combined with Camera Europea sashes and the large with Multilocking mechanism sashes.

Single glazing from 5mm and double glazing up to 37mm can be attached to the glass sash. The door sashes are combined with plain locking mechanism or multilocking mechanism. Three series of gaskets achieve the sealing of the system.

EUROPA 850 and EUROPA 800 have a common aesthetic design and can be combined perfectly.

Technical data summary:

• Opening system
• Certified for air permeability, water tightness and wind resistance
• Available in 2 sizes of sashes (small, large).
• Safety profiles using perimetric locking mechanism for maximum security.
• 3 rows of rubber between the frame and sash provide ultimate sealing.
• Single glazing from 5mm and double glazing up to 37mm.
• USAGE: Opening systems (entrance doors and windows (tilting or not) etc.).

CONSTRUCTION TYPES

• Entrance doors.
• Opening (tilting or not) windows of any typology.
• Fixed Glazing.
• Mixed constructions.
• Opening windows for multilocking mechanism.
